Technial Parameter
LF Unit: 1x12＂(65mm) Driver Unit
HF Unit: 1x44 mm Driver Unit
Power: 400W(RMS) 800W(PEAK)
Frequency Response: 60Hz-20KHz (±3dB)
Sensitivity: 97dB/1W/1M
Max. SPL: 116dB(RMS) 122dB(PEAK)
Nominal Impedance: 8Ω
Cover Range: 70°× 60°(H×V)
Hanging Hardware: 12 x M8 screws hanging point
Handle: 1
Bracket fixed seat: 35mm base bracket hole
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density fiberboard
Weight: 18Kg
Size(W×D×H）: 356x380x610mm
