F-12

F-12

Power 300W(RMS) 600W(PEAK)

Frequency Response 48Hz-18KHz

Sensitivity 97dB/1W/1M

Nominal Impedance 8Ω

Technial Parameter
LF Unit: 1x12＂(65mm) Driver Unit
HF Unit: 1x34 mm Driver Unit
Power: 300W(RMS) 600W(PEAK)
Frequency Response: 48Hz-18KHz (-3dB)
Sensitivity: 97dB/1W/1M
Max. SPL: 122dB(RMS) 128dB(PEAK)
Nominal Impedance: 8Ω
Cover Range: 90°× 50°(H×V)
Hanging Hardware: 8 x M8 Hanging hole
Handle: 2
Bracket fixed seat: 35mm Bracket fixed seat
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density fiberboard
Weight:KG
Size(W×D×H）：mm
Applications
F-12

Outdoor Mini-performances

F-12

Church

F-12

Deluxe Bar

F-12

Deluxe Bar
