Technial Parameter
LF Unit: 1x8＂(65mm) Driver Unit
HF Unit: 1x34 mm Driver Unit
Power: 230W(RMS) 460W(PEAK)
Frequency Response: 65Hz-18KHz (±3dB)
Sensitivity: 94dB/1W/1M
Max. SPL: 107dB(RMS) 119dB(PEAK)
Nominal Impedance: 8Ω
Cover Range: 80°× 50°(H×V)
Hanging Hardware: 14×M8 Hanging hole
Handle: 1
Bracket fixed seat: 35mm base bracket hole
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density poplar plywood
Weight: 11Kg
Size: (W x D x H): 335X488X395mm
