R-15

R-15

Power 600W(RMS) 1200W(PEAK)

Frequency Response 48Hz-20KHz

Sensitivity 102dB/1W/1M

Nominal Impedance 8Ω

Technial Parameter
LF Unit: 1x15＂(75mm) Driver Unit
HF Unit: 1x44 mm Driver Unit
Power: 600W(RMS) 1200W(PEAK)
Frequency Response: 48Hz-20KHz (-3dB)
Sensitivity: 102dB/1W/1M
Max. SPL: 135dB(RMS) 141dB(PEAK)
Nominal Impedance: 8Ω
Cover Range: 60°× 40°(H×V)
Hanging Hardware: 8 x M8 Hanging hole
Handle: 2
Bracket fixed seat: 35mm Bracket fixed seat
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density poplar plywood
Weight: 23.8KG
Size(W×D×H）：428X443X682mm
Applications
R-15

Outdoor Mini-performances

R-15

Church

R-15

Deluxe Bar

R-15

Deluxe Bar
