PS-15

PS-15

Power 350W(RMS) 700W(PEAK)

Frequency Response 55Hz-20KHz

Sensitivity 103dB/1W/1M

Nominal Impedance 8Ω

Technial Parameter
LF Unit: 1x15＂(75mm) Driver Unit
HF Unit: 1x44 mm Driver Unit
Power: 350W(RMS) 700W(PEAK)
Frequency Response: 55Hz-20KHz (-3dB)
Sensitivity: 103dB/1W/1M
Max. SPL: 128dB(RMS) 134dB(PEAK)
Nominal Impedance: 8Ω
Cover Range: 50°-100°× 55°(H×V)
Hanging Hardware: 8 x M8 Hanging hole
Handle: 2
Bracket fixed seat: 35mm Bracket fixed seat
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density fiberboard
Weight: 22.6KG
Size(W×D×H）：430X370X695mm
Applications
PS-15

Lecture Hall

PS-15

Assembly Hall

PS-15

Meeting Room

PS-15

Church
