M-10 PROFESSIONAL STAGE MONITORS

M-10 PROFESSIONAL STAGE MONITORS

Power 400W(RMS) 800W(PEAK)

Frequency Response 50Hz-18KHz

Sensitivity 96dB/1W/1M

Nominal Impedance 8Ω

Technial Parameter
LF Unit: 1x10"（65mm）Coaxial Driver Unit
Power: 400W(RMS) 800W(PEAK)
Frequency Response: 50Hz-18KHz (±3dB)
Sensitivity: 96dB/1W/1M
Max. SPL: 116dB (RMS) 122dB (PEAK)
Nominal Impedance: 8Ω
Cover Range: 60°× 40°(H×V)
Hanging Hardware: 4 x M8 screws hanging point
Handle: 2
Bracket fixed seat: 35mm base bracket hole
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density fiberboard
Weight:  11KG
Size: (W x D x H):  318x352x268mm
Applications
M-10 PROFESSIONAL STAGE MONITORS

Outdoors

M-10 PROFESSIONAL STAGE MONITORS

Outdoors

M-10 PROFESSIONAL STAGE MONITORS

Indoors

M-10 PROFESSIONAL STAGE MONITORS

Music Show

M-10 PROFESSIONAL STAGE MONITORS

Deluxe Bar

M-10 PROFESSIONAL STAGE MONITORS

Outdoor Mini-performances

M-10 PROFESSIONAL STAGE MONITORS

Assembly Hall

M-10 PROFESSIONAL STAGE MONITORS

Lecture Hall
