Technial Parameter
LF Unit: 1x8＂（50mm）Driver Unit
HF Unit: 1x34 mm Driver Unit
Power: 250W (RMS) 500W (PEAK)
Frequency Response: 60Hz-18KHz  (±3dB)
Sensitivity: 97dB / 1W / 1M
Max. SPL: 108dB (RMS) 114dB (PEAK)
Nominal Impedance: 8Ω
Cover Range: 90°× 50°(H×V)
Hanging Hardware: 14 x M8 screws hanging point
Bracket fixed seat: Yes
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density poplar plywood
Weight: 14Kg
Size(W×D×H）: 270x300x485mm
