Technial Parameter
LF Unit: 1x15"（75mm）Driver Unit
HF Unit: 1x44 mm Driver Unit
Power: 500W (RMS) 1000W (PEAK)
Frequency Response: 60Hz-18KHz  (±3dB)
Sensitivity: 103dB / 1W / 1M
Max. SPL: 116dB (RMS) 122dB (PEAK)
Nominal Impedance: 8Ω
Cover Range: 90°× 50°(H×V)
Hanging Hardware: 18 x M8 screws hanging point
Handle: 1
Bracket fixed seat: 35mm base bracket hole
Connector: 2×NL4 Socket, +1, -1
Box Material: CNC manufacturing, high density poplar plywood
Weight: 27Kg
Size(W×D×H）: 480x500x680mm
