D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Power 110W(RMS) 220W(PEAK)

Frequency Response 28Hz-20KHz

Sensitivity 99dB/1W/1M

Nominal Impedance 8Ω

Technial Parameter
LF Unit: 1x5” Glass fiber tweeter unit
HF Unit: 1x4” magnetically shielded natural silk dome
Power: 110W (RMS) 220W (PEAK)
Frequency Response: 28Hz-20KHz (±3dB)
Sensitivity: 99dB / 1W / 1M
Max. SPL: 123dB (RMS) 129dB (PEAK)
Nominal Impedance: 8Ω
Input Connector: 1×20KΩ balance XLR
Cabinet: Vinyl-laminated  high-acoustic-efficiency  MDF
Power  Requirements: 220V-240V~T1.6AL 50Hz/60Hz
Weight: 4.65Kg
Size(W×D×H): 200x320x220mm

Applications
D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Background Music

D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Convenience Store

D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Record Shop

D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Public Address System

D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Cafe Shop

D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Recording Room

D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Beauty Salon

D-5 PROFESSIONAL ACTIVE MONITOR SYSTEM

Music Bar
